INSTEON Hub Developer's Guide

INSTEON Hub: Developer’s Guide
Page 22 © 2013 INSTEON
INSTEON Standard Message Received
INSTEON Standard Message Received (0x50)
What it does
Informs you of an incoming Standard-length INSTEON message.
When you’ll get this A Standard-length INSTEON message is received from either a Controller or Responder that you are
ALL-Linked to.
What you’ll get
11 bytes.
LED indication
The LED will blink during INSTEON reception.
Related Commands
IM 0x51 INSTEON Extended Message Received
23
IM 0x52 X10 Received
28
Message Sent from IM to Host
Byte Value Meaning
1 0x02 Start of IM Command
2
0x50
IM Command Number
3 <From Address high> The high byte of the INSTEON ID of the message originator.
4 <From Address middle> The middle byte of the INSTEON ID of the message originator.
5 <From Address low> The low byte of the INSTEON ID of the message originator.
6 <To Address high> The high byte of the INSTEON ID of the message addressee.
If the message is an ALL-Link Broadcast (bits 7 and 6 of the <Message Flags> byte are
set) then this will be 0.
7 <To Address middle> The middle byte of the INSTEON ID of the message addressee.
If the message is an ALL-Link Broadcast (bits 7 and 6 of the <Message Flags> byte are
set) then this will be 0.
8 <To Address low> The low byte of the INSTEON ID of the message addressee.
If the message is an ALL-Link Broadcast (bits 7 and 6 of the <Message Flags> byte are
set) then this will indicate the ALL-Link Group Number.
9 <Message Flags> The INSTEON message flags indicating message type and hops.
10 <Command 1> INSTEON Command 1 field of the message.
11 <Command 2> INSTEON Command 2 field of the message.
This byte contains the ALL-Link Group Number of the ALL-Link Broadcast when either
bit 6 of the <Message Flags> byte is set (ALL-Link Cleanup) or bits 6 and 5 of the
<Message Flags> byte are set (ALL-Link Cleanup ACK).
Notes
This is the same as IM 0x51 INSTEON Extended Message Received
23
, except that there is no <User
Data>.
Normally, the IM will only send the host INSTEON messages that are explicitly addressed to the IM or
that are from devices that the IM is ALL-Linked to. This behavior can be modified—see the About Monitor
Mode
46
note in the Set IM Configuration
46
chart for more information.
For more information on INSTEON Commands and the latest Command set, please download the current
INSTEON Command Tables Document
2
from http://code.insteon.com.

INSTEON Hub Specifications

General

Product Name	INSTEON Hub
Model Number	2245-222
Connectivity	Ethernet
Communication Protocol	INSTEON
Operating Temperature	0°C to 40°C (32°F to 104°F)
Operating Humidity	85% non-condensing
