INSTEON Hub Developer's Guide

INSTEON Hub: Developer’s Guide
Page 44 © 2013 INSTEON
User Reset Detected
User Reset Detected (0x55)
What it does
Reports that the user manually put the IM into the IM Factory Reset State
11
.
When you’ll get this
The user held down the IM’s SET Button for at least 10 seconds when power was first applied.
What you’ll get
2 bytes (not until about 20 seconds after applying power to the IM with the SET Button held down).
LED indication
The LED will turn off for about 20 seconds. Once the LED turns back on the reset is complete.
Related Commands
IM 0x67 Reset the IM
43
Message Sent from IM to Host
Byte Value Meaning
1 0x02 Start of IM Command
2
0x55
IM Command Number
Notes
The IM will send this message after it erases the EEPROM.
~20 seconds for models with external EEPROM (for product revisions less than 2.4 or firmware
verisons 52 or earlier.
~2 seconds for models with no external EEPROM
Effective with product revisions 2.5 or greater, the reset time is reduced to ~3 seconds.
See the IM Factory Reset State
11
section for complete information on the state of the IM after receiving
this message.

INSTEON Hub Specifications

General

Product Name	INSTEON Hub
Model Number	2245-222
Connectivity	Ethernet
Communication Protocol	INSTEON
Operating Temperature	0°C to 40°C (32°F to 104°F)
Operating Humidity	85% non-condensing
