X10 Message Handling
Send X10
Send X10 (0x63)
What it does
Allows you to send a raw X10 Address or X10 Command.
What you send
4 bytes.
What you’ll get
5 bytes.
LED indication
None.
Related Commands
IM 0x52 X10 Received
28
Command Sent from Host to IM
Byte Value Meaning
1 0x02 Start of IM Command
2
0x63
IM Command Number
3 <Raw X10> The four most significant bits contain the X10 House Code.
The four least significant bits contain the X10 Key Code.
4 <X10 Flag> 0x00 indicates that the X10 Key Code is an X10 Unit Code.
0x80 indicates that the X10 Key Code is an X10 Command.
Message Returned by IM to Host
Byte Value Meaning
1 0x02 Echoed Start of IM Command
2
0x63
Echoed IM Command Number
3 <Raw X10> Echoed <Raw X10>
4 <X10 Flag> Echoed <X10 Flag>
5 <ACK/NAK> 0x06 (ACK) if the IM executed the Command correctly
0x15 (NAK) if an error occurred
X10 Translation Table
4 MSBs of <Raw X10> 4 LSBs of <Raw X10>
4-bit
Code
X10 House Code X10 Unit Code
<X10 Flag> = 0x00
X10 Command
<X10 Flag> = 0x80
0x6 A 1 All Lights Off
0xE B 2 Status = Off
0x2 C 3 On
0xA D 4 Preset Dim
0x1 E 5 All Lights On
0x9 F 6 Hail Acknowledge
0x5 G 7 Bright
0xD H 8 Status = On
0x7 I 9 Extended Code
0xF J 10 Status Request
0x3 K 11 Off
0xB L 12 Preset Dim
0x0 M 13 All Units Off
0x8 N 14 Hail Request
0x4 O 15 Dim
0xC P 16 Extended Data (analog)

INSTEON Hub Specifications

General

Product Name	INSTEON Hub
Model Number	2245-222
Connectivity	Ethernet
Communication Protocol	INSTEON
Operating Temperature	0°C to 40°C (32°F to 104°F)
Operating Humidity	85% non-condensing
