INSTEON Hub Developer's Guide

INSTEON Hub: Developer’s Guide
Page 51 © 2013 INSTEON
IM Input/Output
Button Event Report
Button Event Report (0x54)
What it does
Reports user SET Button events.
When you’ll get this
The user operates the SET Button, or if they exist, Button 2 or Button 3.
What you’ll get
3 bytes.
LED indication If the event is SET Button Press and Hold the IM will automatically go into ALL-Linking mode which
will cause the LED to blink continuously at a rate of ½ second on and ½ second off. Automatic
linking may be turned off by setting IM Configuration Flags bit 7 (see Set IM Configuration
46
).
Related Commands
IM 0x53 ALL-Linking Completed
35
IM 0x64 Start ALL-Linking
33
IM 0x65 Cancel ALL-Linking
34
Message Sent from IM to Host
Byte Value Meaning
1 0x02 Start of IM Command
2
0x54
IM Command Number
3 <Button Event> Indicates the type of SET Button event that occurred.
0x02 The SET Button was Tapped
0x03 There was a SET Button Press and Hold for more than three seconds.
This automatically puts the IM into ALL-Linking mode unless IM Configuration
Flags bit 7 is set.
0x04
The SET Button was released after a SET Button Press and Hold event was
recorded.
0x12 Button 2 was Tapped
0x13 There was a Button 2 Press and Hold for more than three seconds.
0x14 Button 2 was released after a Button 2 Press and Hold event was recorded.
0x22 Button 3 was Tapped
0x23 There was a Button 3 Press and Hold for more than three seconds.
0x24 Button 3 was released after a Button 3 Press and Hold event was recorded.

INSTEON Hub Specifications

General

Product Name	INSTEON Hub
Model Number	2245-222
Connectivity	Ethernet
Communication Protocol	INSTEON
Operating Temperature	0°C to 40°C (32°F to 104°F)
Operating Humidity	85% non-condensing
