ID Request Example:
http://172.16.1.34/3?02620E79860F1000=I=3
The buffer will have
02620E79860F10000602500E798609D6822B100002500E798601009C8B0100
0262 Pass through Command to PLM
0E7986 Insteon ID
0F Flags
10 CMD1
00 CMD2
06
0250 Insteon Message
0E7986 From
09D682 To
2B Flags Byte 20 = ACK + B = Hop count
10 Echo CMD1
00 Echo CMD2
0250 Insteon Message (about 1 sec later)
0E7986 From
01 Cat (01 = Dimmer)
00 (SubCat) (00 = LampLinc)
9C Firmware version
8B Flags Byte 80 = Broadcast + B = hop count
01 CMD1 01 = ID Request
00 CMD2 00 = Ignore
Status Request Example:
http://172.16.1.34/3?02620E79860F1900=I=3
The buffer will have
02620E79860F19000602500E798609D6822B03FF
0262 Pass Through
0E7986 ID
0F Flags
19 CMD1 Status Request
00 CMD2
06
0250 Insteon Received
0E7986 From
09D682 To
2B 20 = ACK + B = Hop Count
03 03 is the Delta…gets changed every time EE is changed (Ignore)
FF Current On Level could be 00 – FF
Note: Status Request returns Info in the ACK while ID request generates

INSTEON Hub Specifications

General

Product Name	INSTEON Hub
Model Number	2245-222
Connectivity	Ethernet
Communication Protocol	INSTEON
Operating Temperature	0°C to 40°C (32°F to 104°F)
Operating Humidity	85% non-condensing
