INSTEON Hub Developer's Guide

INSTEON Hub: Developer’s Guide
Page 43 © 2013 INSTEON
IM Status Management
Reset the IM
Reset the IM (0x67)
What it does
Puts the IM into the IM Factory Reset State
11
, which clears the entire ALL-Link Database.
What you send
2 bytes.
What you’ll get
3 bytes.
LED indication While the reset procedure is being processed, the Status LED will turn off. At the conclusion of the
reset procedure, the Status LED will illuminate steadily.
Related Commands
IM 0x55 User Reset Detected
44
Command Sent from Host to IM
Byte Value Meaning
1 0x02 Start of IM Command
2
0x67
IM Command Number
Message Returned by IM to Host
Byte Value Meaning
1 0x02 Echoed Start of IM Command
2
0x67
Echoed IM Command Number
3 <ACK/NAK>
0x06 (ACK) if the IM executed the Command correctly
0x15 (NAK) if an error occurred
Notes
The IM will send the <ACK/NAK> byte after it erases the EEPROM.
~20 seconds for models with external EEPROM (for product revisions less than 2.4 or firmware
verisons 52 or earlier.
~2 seconds for models with no external EEPROM
Effective with product revisions 2.5 or greater, the reset time is reduced to ~3 seconds.
See the IM Factory Reset State
11
section for complete information on the state of the IM after sending
this Command.

INSTEON Hub Specifications

General

Product Name	INSTEON Hub
Model Number	2245-222
Connectivity	Ethernet
Communication Protocol	INSTEON
Operating Temperature	0°C to 40°C (32°F to 104°F)
Operating Humidity	85% non-condensing
