5. Development Kit Hardware and Configuration
The Intel Agilex 7 FPGA I-Series Transceiver (6 × F-Tile) Development Kit can support
multiple application scenarios and configuration modes. You need to change hardware
setting and/or re-program system images for these cases.
Table 4. Supported Configuration Modes
S9 [1:4] MSEL [2:0] Configuration Mode
ON/OFF/OFF/X 001 AS – Fast mode (Default setting)
ON/ON/OFF/X 011 AS – Normal mode
ON/ON/ON/X 111 JTAG
OFF/ON/ON/X 110 Avalon-ST x8
5.1. Configure the FPGA Device by Active Serial (AS) Modes
(Default Mode)
1. Default S9 setting and system Intel MAX 10 image support AS configuration
mode.
2. Plug pre-programmed SDM QSPI flash daughter into J3.
3. Power on and observe FPGA User_LED turn on, and User_LED6 and User_LED7
blink.
5.2. Configure the FPGA Device by Avalon
®
-ST (AvST) Modes
1. Set S9 to AvST x8 mode first.
2. Default system Intel MAX 10 image support AvST x8 mode only.
3. Restart the board and program the flash device. sys_led6 and sys_led7 are both
turn on.
4. Restart until D14 and D16 lights turn on.
5. Select image using PB4 or S17.
6. When the correct page is selected, User_LED[1:5] turn on, and User_LED6 and
User_LED7 blink.
