Page #6 background imageLoading...
Page #6 background image
1.3. Box Contents
Intel Agilex 7 FPGA I-Series Transceiver Development Kit
Single-rank DDR4 DIMM module
QSPI flash daughter card
USB2.0 Type B cable
1 × 240 W power adapter and NA/EU/JP/UK cords
1.4. Recommended Operating Conditions
Table 2. Recommended Operating Conditions
Operating Condition Range of Values
Ambient operating temperature range 0°C to 35 °C
ICC load current 50 A
ICC load transient percentage 269 A/uS
FPGA maximum power supported by active heat sink/fan 300 W
When handling the board, it is important to observe static discharge precautions.
Note: Caution: Without proper anti-static handling, the board can be damaged. Therefore,
use anti-static handling precautions when touching the development kit.
Note: Caution: This development kit should not be operated in a vibration environment.
1. Overview
776646 | 2023.05.31
Intel Agilex
®
7 FPGA I-Series Transceiver (6 × F-Tile) Development Kit User
Guide
Send Feedback
6
