3. Power Up the Development Kit
The instructions in this chapter explain how to setup the Intel Agilex 7 FPGA I-Series
Transceiver Development Kit for specific use cases.
3.1. Default Settings
The Intel Agilex 7 FPGA I-Series Transceiver Development Kit ships with its board
switches preconfigured to support the design examples in the kit. If you suspect your
board might not be correctly configured with the default settings, follow the
instructions in the factory default switch settings table to return to its factory settings
before proceeding ahead.
Note: X refers to Don't Care in the table below.
Table 3. Factory Default Switch Settings
Switch Default Position Default Function
S19 [1:4]
ON / OFF/ ON / ON System MAX-10 selected I JTAG Chain
S20 [1:4]
ON / ON / ON / ON Mode 1: On-board Intel download circuit act as the only JTAG Master.
S9[1:4]
ON / OFF / OFF / X Agilex FPGA Mode Select pins.
Default JTAG
S10 [1:4]
ON / ON / ON / ON SYS_SW[0:3]
SYS_SW[0]–-> Factory Loadn
‘0’ – Load image from Page 0 of the QSPI
S15 [1:4]
ON / ON / ON / OFF SYS_SW[4:7]
SYS_SW[4]-->X
SYS_SW[5]–->
FMC-A PCIe RP/EP Select
“0”: RP (Default)
“1”: EP
SYS_SW[6]–->
FMC-B PCIex RP/EP Select
“0”: RP (Default)
“1”: EP
SYS_SW[7]–->
Not used
“0”: RP
“1”: EP (Default)
S1[1:4]
S6 [1:4]
OFF /OFF / OFF / OFF
OFF / OFF/ OFF / OFF
User Switch [0:3]
User Switch [4:7]
S22[1:4]
ON / ON / ON / ON MUX_DIP_SW[0:3]
continued...
