1.2. Feature Summary
Intel Agilex 7 I-Series FPGA, 2.7M LE, 3948B package
F-Tile 1 (12A):
16 FGT transceiver channels fan out to FMC+ connector
F-Tile 2 (12B):
4 FHT transceiver channels fan out to Quad Small Form Factor Double Density
800 connector (QSFPDD800)
8 FGT transceiver channels to Quad Small Form Factor Double Density
connector
4 FGT Transceiver channels to Quad Small Form Factor connector
F-Tile 3 (12C):
4 FHT transceiver channels fan out to Quad Small Form Factor Double Density
800 connector (QSFPDD800)
8 FGT transceiver channels to Quad Small Form Factor Double Density
connector
4 FGT Transceiver channel to Small Form Factor connector
4 FGT transceiver to channels to Quad Small Form Factor connector
F-Tile 4 (13A):
4 FGT Transceiver to channels to Quad Small Form Factor connector
8 FGT transceiver channels to Quad Small Form Factor Double Density
connector
F-Tile 5 (13B):
4 FGT Transceiver to channels to MCIO
8 FGT transceiver channels to Quad Small Form Factor Double Density
connector
4 FHT transceiver channels fan out to Octal Small Form Factor connector
F-Tile 6 (13C):
16 FGT channels to FMC+
4 FHT transceiver channels fan out to Octal Small Form Factor connector
SR DDR4 2666 MT/s (× 72 w/ECC), 16 GB.
SR DDR4 2666 MT/s (× 72 w/ECC), 16 GB 1 DPC DIMM connector
Note: QSFPDD and OSFP work up to 400 Gbps (50 G x 8) PAM4 in DK-SI-AGI040FES.
QSFPDD800 and OSFP work up to 800 Gbps (100 G x 8) PAM4 in DK-SI-AGI040EA.
1. Overview
776646 | 2023.05.31
Send Feedback
Intel Agilex
®
7 FPGA I-Series Transceiver (6 × F-Tile) Development Kit User
Guide
5
