Intel Agilex 7 FPGA I-Series User Manual

Temperature
Reads the temperature data from temperature sense diodes inside the FPGA die or
assembled on PCB.
Local Temp
Shows the temperature comparison of local and remote temperature sensors.
Beta Comp
Enables beta compensation for temperature sensing chips.
Temperature Range for Fan Control
Sets and displays the temperature range for fan control. This part information is store
in the first 8 bytes of EEPROM(U114). Please pay attention to not overwrite it.
4.5. Identify Test Pass or Fail-based on BTS GUI Test Status
QSFPDD0/QSFPDD1/ QSFPDD2/QSFPDD3
Plug QSFPDD0/QSFPDD1/QSFPDD2/QSFPDD3 loopback module in J27/J48/J69/J67
before you configure QSFPDD NRZ example build through BTS GUI.
QSFPDD800
Plug QSFPDD800 loopback module in J22 before you configure QSFPDD800 PAM4
example build through BTS GUI.
FMCA/FMCB
Plug FMCA/FMCB loopback module in J7/J9 before you configure FMCA/FMCB NRZ
example build through BTS GUI.
QSFP
Plug QSFP loopback module in J57/J58/J66 before you configure QSFP NRZ example
build through BTS GUI.
OSFP
Plug OSFP loopback module in J45 before you configure OSFP NRZ example build
through BTS GUI.
SFP
Plug four SFP loopback modules in J77 before you configure SFP NRZ example build
through BTS GUI.
DDR4 DIMM
Plug the DIMM module which is shipped alone with this development kit in J5.
4. Board Test System
776646 | 2023.05.31
Send Feedback
Intel Agilex
®
7 FPGA I-Series Transceiver (6 × F-Tile) Development Kit User
Guide
29
