Intel Agilex 7 FPGA I-Series User Manual

A.1.2. Board Components
Table 6. Board Connector/Switch Description
Connector/Switch Description
J30 12V AUX1 CONN
J55 12V AUX2 CONN
J3 SDM CONN
J38 FAN0 CONN[CORE FET FAN]
J7 FMCA CONN
J9 FMCB CONN
J57 QSFP0 CONN
J27 QSFP-DD0 CONN
J22 QSFP-DD800 CONN
J58 QSFP1 CONN
J48 QSFP-DD1 CONN
J77 SFP CONN
J6 SI5395-2 IN1N CONN
J4 SI5395-2 IN1P CONN
J34 FAN1 CONN[QSFP LEFT FAN]
J79 TEMP SENSOR I2C CONN
J149 CURRENT SENSOR I2C CONN
J43 FAN2 CONN[FPGA FAN]
J37 MCIO CONN
J5 DIMM CONN
J44 FAN3 CONN[QSFP RIGHT FAN]
J45 OSFP CONN
J67 QSFP-DD3 CONN
J66 QSFP2 CONN
J69 QSFP-DD2 CONN
J25 10MHz IN CONN
J12 SI5395-1 IN1N CONN
J8 SI5395-1 IN1P CONN
J17 10MHz OUT CONN
J140 CLOCK I2C CONN
J41 PMBUS CONN
J21 ToD CONN
J31 SI5518 SPI CONN
J42 CLOCK I2C CONN
continued...
A. Development Kit Components
776646 | 2023.05.31
Intel Agilex
®
7 FPGA I-Series Transceiver (6 × F-Tile) Development Kit User
Guide
Send Feedback
34
