Intel Agilex User Guide

3.2.2.5. FP16 Vector One Mode
This mode performs a summation of two half-precision multiplications with the chainin
input from the previous variable DSP Block. The output is a single-precision floating-
point value which is fed into chainout.
Table 19. Equations Applied to FP16 Vector One Mode
Chainin Parameter Vector One with Floating-Point
Addition
Vector One with Floating-Point
Subtraction
Disable fp32_result = (fp16_mult_top_a *
fp16_mult_top_b) + (fp16_mult_bot_a
* fp16_mult_bot_b)
Chainout = fp32_adder_a
fp32_result = (fp16_mult_top_a *
fp16_mult_top_b) - (fp16_mult_bot_a
* fp16_mult_bot_b)
Chainout = fp32_adder_a
Enable fp32_result = (fp16_mult_top_a *
fp16_mult_top_b) + (fp16_mult_bot_a
* fp16_mult_bot_b) + fp32_chainin
Chainout = fp32_adder_a
fp32_result = (fp16_mult_top_a *
fp16_mult_top_b) - (fp16_mult_bot_a
* fp16_mult_bot_b) - fp32_chainin
Chainout = fp32_adder_a
The following are exception flags supported in flushed and bfloat16 formats:
•
fp16_mult_top_invalid
•
fp16_mult_top_inexact
•
fp16_mult_top_overflow
•
fp16_mult_top_underflow
•
fp16_mult_bot_invalid
•
fp16_mult_bot_inexact
•
fp16_mult_bot_overflow
•
fp16_mult_bot_underflow
•
fp16_adder_invalid
•
fp16_adder_inexact
•
fp16_adder_overflow
•
fp16_adder_underflow
•
fp32_adder_invalid
•
fp32_adder_inexact
•
fp32_adder_overflow
•
fp32_adder_underflow
The following are exception flags supported in extended format:
•
fp16_mult_top_invalid
•
fp16_mult_top_inexact
•
fp16_mult_top_infinite
•
fp16_mult_top_zero
•
fp16_mult_bot_invalid
•
fp16_mult_bot_inexact
3. Intel Agilex Variable Precision DSP Blocks Operational Modes
UG-20213 | 2019.04.02
Intel
®
Agilex
™
Variable Precision DSP Blocks User Guide
Send Feedback
50
