104 Datasheet
Intel
®
Celeron
®
Processor up to 1.10 GHz
AJ1 A21# AGTL+ I/O
AJ3 GND Power/Other
AJ5 V
CC
CORE
Power/Other
AJ7 GND Power/Other
AJ9 V
CC
CORE
Power/Other
AJ11 GND Power/Other
AJ13 V
CC
CORE
Power/Other
AJ15 GND Power/Other
AJ17 V
CC
CORE
Power/Other
AJ19 GND Power/Other
AJ21 V
CC
CORE
Power/Other
AJ23 GND Power/Other
AJ25 V
CC
CORE
Power/Other
AJ27 GND Power/Other
AJ29 V
CC
CORE
Power/Other
AJ31 BSEL1
5
Power/Other
AJ33 BSEL0 CMOS I/O
AJ35 SMI# CMOS Input
AJ37 VID3 Power/Other
AK2 V
CC
CORE
Power/Other
AK4 GND Power/Other
AK6 A28# AGTL+ I/O
AK8 A3# AGTL+ I/O
AK10 A11# AGTL+ I/O
AK12 V
REF6 Power/Other
AK14 A14# AGTL+ I/O
AK16 Reserved Reserved for future use
AK18 REQ0# AGTL+ I/O
AK20 LOCK# AGTL+ I/O
AK22 V
REF7 Power/Other
AK24 Reserved Reserved for future use
AK26 PWRGOOD CMOS Input
AK28 RS2# AGTL+ Input
AK30 Reserved Reserved for future use
AK32 TMS TAP Input
AK34 V
CC
CORE
Power/Other
AK36 GND Power/Other
AL1 GND Power/Other
AL3 GND Power/Other
Table 56. FC-PGA/FC-PGA2 Signal
Listing in Order by Pin
Number
Pin
No.
Pin Name Signal Group
AL5 A15# AGTL+ I/O
AL7 A13# AGTL+ I/O
AL9 A9# AGTL+ I/O
AL11 Reserved Reserved for future use
AL13 Reserved Reserved for future use
AL15 A7# AGTL+ I/O
AL17 REQ4# AGTL+ I/O
AL19 REQ3# AGTL+ I/O
AL21 Reserved Reserved for future use
AL23 HITM# AGTL+ I/O
AL25 HIT# AGTL+ I/O
AL27 DBSY# AGTL+ I/O
AL29 THERMDN Power/Other
AL31 THERMDP Power/Other
AL33 TCK TAP Input
AL35 VID0 Power/Other
AL37 VID2 Power/Other
AM2 Reserved
3
Reserved for future use
AM4 V
CC
CORE
Power/Other
AM6 GND Power/Other
AM8 V
CC
CORE
Power/Other
AM10 GND Power/Other
AM12 V
CC
CORE
Power/Other
AM14 GND Power/Other
AM16 V
CC
CORE
Power/Other
AM18 GND Power/Other
AM20 V
CC
CORE
Power/Other
AM22 GND Power/Other
AM24 V
CC
CORE
Power/Other
AM26 GND Power/Other
AM28 V
CC
CORE
Power/Other
AM30 GND Power/Other
AM32 V
CC
CORE
Power/Other
AM34 GND Power/Other
AM36 VID1 Power/Other
AN3 GND Power/Other
AN5 A12# AGTL+ I/O
AN7 A16# AGTL+ I/O
AN9 A6# AGTL+ I/O
Table 56. FC-PGA/FC-PGA2 Signal
Listing in Order by Pin
Number
Pin
No.
Pin Name Signal Group
