Intel CELERON 1.10 GHZ User Manual

Datasheet 105
Intel
®
Celeron
®
Processor up to 1.10 GHz
AN11 Reserved Reserved for future use
AN13 Reserved Reserved for future use
AN15 Reserved Reserved for future use
AN17 BPRI# AGTL+ Input
AN19 DEFER# AGTL+ Input
AN21 Reserved Reserved for future use
AN23 Reserved Reserved for future use
AN25 TRDY# AGTL+ Input
AN27 DRDY# AGTL+ I/O
AN29 BR0# AGTL+ I/O
AN31 ADS# AGTL+ I/O
AN33 TRST# TAP Input
AN35 TDI TAP Input
AN37 TDO TAP Output
B2 D35# AGTL+ I/O
B4 GND Power/Other
B6 V
CC
CORE
Power/Other
B8 GND Power/Other
B10 V
CC
CORE
Power/Other
B12 GND Power/Other
B14 V
CC
CORE
Power/Other
B16 GND Power/Other
B18 V
CC
CORE
Power/Other
B20 GND Power/Other
B22 V
CC
CORE
Power/Other
B24 GND Power/Other
B26 V
CC
CORE
Power/Other
B28 GND Power/Other
B30 V
CC
CORE
Power/Other
B32 GND Power/Other
B34 V
CC
CORE
Power/Other
B36 Reserved Reserved for future use
C1 D33# AGTL+ I/O
C3 V
CC
CORE
Power/Other
C5 D31# AGTL+ I/O
C7 D34# AGTL+ I/O
C9 D36# AGTL+ I/O
C11 D45# AGTL+ I/O
C13 D49# AGTL+ I/O
Table 56. FC-PGA/FC-PGA2 Signal
Listing in Order by Pin
Number
Pin
No.
Pin Name Signal Group
C15 D40# AGTL+ I/O
C17 D59# AGTL+ I/O
C19 D55# AGTL+ I/O
C21 D54# AGTL+ I/O
C23 D58# AGTL+ I/O
C25 D50# AGTL+ I/O
C27 D56# AGTL+ I/O
C29 Reserved Reserved for future use
C31 Reserved Reserved for future use
C33 Reserved Reserved for future use
C35 BPM0# AGTL+ I/O
C37 CPUPRES# Power/Other
D2 GND Power/Other
D4 GND Power/Other
D6 V
CC
CORE
Power/Other
D8 D38# AGTL+ I/O
D10 D39# AGTL+ I/O
D12 D42# AGTL+ I/O
D14 D41# AGTL+ I/O
D16 D52# AGTL+ I/O
D18 GND Power/Other
D20 V
CC
CORE
Power/Other
D22 GND Power/Other
D24 V
CC
CORE
Power/Other
D26 GND Power/Other
D28 V
CC
CORE
Power/Other
D30 GND Power/Other
D32 V
CC
CORE
Power/Other
D34 GND Power/Other
D36 V
CC
CORE
Power/Other
E1 D26# AGTL+ I/O
E5 V
CC
CORE
Power/Other
E7 GND Power/Other
E9 V
CC
CORE
Power/Other
E11 GND Power/Other
E13 V
CC
CORE
Power/Other
E15 GND Power/Other
E17 V
CC
CORE
Power/Other
E19 GND Power/Other
Table 56. FC-PGA/FC-PGA2 Signal
Listing in Order by Pin
Number
Pin
No.
Pin Name Signal Group
