Quad-Core Intel® Xeon® Processor 5300 Series Datasheet 35
Electrical Specifications
Notes:
1. The V
CC_MIN
and V
CC_MAX
loadlines represent static and transient limits. Please see Section 2.13.2 for VCC
overshoot specifications.
2. Refer to Table 2-12 for processor VID information.
3. Refer to Table 2-13 for V
CC
Static and Transient Tolerance
90 VID - 0.113 VID - 0.128 VID - 0.143 1, 2, 3, 4
95 VID - 0.119 VID - 0.134 VID - 0.149 1, 2, 3, 4
100 VID - 0.125 VID - 0.140 VID - 0.155 1, 2, 3, 4
105 VID - 0.131 VID - 0.146 VID - 0.161 1, 2, 3, 4
110 VID - 0.138 VID - 0.153 VID - 0.168 1, 2, 3, 4
115 VID - 0.144 VID - 0.159 VID - 0.174 1, 2, 3, 4
120 VID - 0.150 VID - 0.165 VID - 0.180 1, 2, 3, 4
125 VID - 0.156 VID - 0.171 VID - 0.186 1, 2, 3, 4
Notes:
1. The V
CC_MIN
and V
CC_MAX
loadlines represent static and transient limits. Please see Section 2.13.2 for
V
CC
overshoot specifications.
2. This table is intended to aid in reading discrete points on Figure 2-7 for Quad-Core Intel® Xeon®
Processor E5300 , Figure 2-8 for Quad-Core Intel® Xeon® Processor X5300 Series and Figure 2-9 for
Quad-Core Intel® Xeon® Processor L5300 Series.
3. The loadlines specify voltage limits at the die measured at the VCC_DIE_SENSE and VSS_DIE_SENSE
lands and across the VCC_DIE_SENSE2 and VSS_DIE_SENSE2 lands. Voltage regulation feedback for
voltage regulator circuits must also be taken from processor VCC_DIE_SENSE and VSS_DIE_SENSE
lands and VCC_DIE_SENSE2 and VSS_DIE_SENSE2 lands. Refer to the Voltage Regulator Module (VRM)
and Enterprise Voltage Regulator Down (EVRD) 11.0 Design Guidelines for socket load line guidelines and
VR implementation. Please refer to the appropriate platform design guide for details on VR
implementation.
4. Icc values greater than 90 A and 60 A are not applicable for the Quad-Core Intel® Xeon® Processor
E5300 and Quad-Core Intel® Xeon® Processor L5300 Series, respectively.
Figure 2-7. Quad-Core Intel® Xeon® Processor E5300 Series V
CC
Static and
Transient Tolerance Load Lines
Table 2-13. V
CC
Static and Transient Tolerance for Quad-Core Intel® Xeon® Processor
E5300 Series, Quad-Core Intel® Xeon® Processor X5300 Series, Quad-Core
Intel® Xeon® Processor L5300 Series (Sheet 2 of 2)
I
CC
(A) V
CC_Max
(V) V
CC_Typ
(V) V
CC_Min
(V) Notes
VID - 0.000
VID - 0.020
VID - 0.040
VID - 0.060
VID - 0.080
VID - 0.100
VID - 0.120
VID - 0.140
VID - 0.160
0 5 10 15 20 25 30 35 40 45 50 55 60 65 70 75 80 85 90
Icc [A]
Vcc [V]
V
CC
Maximum
V
CC
Typical
V
CC
Minimum
