Quad-Core Intel® Xeon® Processor 5300 Series Datasheet 69
Land Listing
4.1.2 Land Listing by Land Number
Table 4-2. Land Listing by Land Number
(Sheet 1 of 20)
Pin
No.
Pin Name
Signal
Buffer Type
Direction
A10 D08# Source Sync Input/Output
A11 D09# Source Sync Input/Output
A12 VSS Power/Other
A13 COMP0 Power/Other Input
A14 D50# Source Sync Input/Output
A15 VSS Power/Other
A16 DSTBN3# Source Sync Input/Output
A17 D56# Source Sync Input/Output
A18 VSS Power/Other
A19 D61# Source Sync Input/Output
A2 VSS Power/Other
A20 RESERVED
A21 VSS Power/Other
A22 D62# Source Sync Input/Output
A23 RESERVED
A24 RESERVED
A25 VTT Power/Other
A26 VTT Power/Other
A3 RS2# Common Clk Input
A4 D02# Source Sync Input/Output
A5 D04# Source Sync Input/Output
A6 VSS Power/Other
A7 D07# Source Sync Input/Output
A8 DBI0# Source Sync Input/Output
A9 VSS Power/Other
AA1 VTT_OUT Power/Other Output
AA2 LL_ID1 Power/Other Output
AA23 VSS Power/Other
AA24 VSS Power/Other
AA25 VSS Power/Other
AA26 VSS Power/Other
AA27 VSS Power/Other
AA28 VSS Power/Other
AA29 VSS Power/Other
AA3 VSS Power/Other
AA30 VSS Power/Other
AA4 A21# Source Sync Input/Output
AA5 A23# Source Sync Input/Output
AA6 VSS Power/Other
AA7 VSS Power/Other
AA8 VCC Power/Other
AB1 VSS Power/Other
AB2 IERR# Open Drain
Asynchronous
Output
AB23 VSS Power/Other
AB24 VSS Power/Other
AB25 VSS Power/Other
AB26 VSS Power/Other
AB27 VSS Power/Other
AB28 VSS Power/Other
AB29 VSS Power/Other
AB3 MCERR# Common Clk Input/Output
AB30 VSS Power/Other
AB4 A26# Source Sync Input/Output
AB5 A24# Source Sync Input/Output
AB6 A17# Source Sync Input/Output
AB7 VSS Power/Other
AB8 VCC Power/Other
AC1 TMS TAP Input
AC2 DBR# Power/Other Output
AC23 VCC Power/Other
AC24 VCC Power/Other
AC25 VCC Power/Other
AC26 VCC Power/Other
AC27 VCC Power/Other
AC28 VCC Power/Other
AC29 VCC Power/Other
AC3 VSS Power/Other
AC30 VCC Power/Other
AC4 RESERVED
AC5 A25# Source Sync Input/Output
AC6 VSS Power/Other
AC7 VSS Power/Other
AC8 VCC Power/Other
AD1 TDI TAP Input
AD2 BPM2# Common Clk Output
AD23 VCC Power/Other
AD24 VCC Power/Other
Table 4-2. Land Listing by Land Number
(Sheet 2 of 20)
Pin
No.
Pin Name
Signal
Buffer Type
Direction
