Electrical Specifications
46 Quad-Core Intel® Xeon® Processor 5300 Series Datasheet
§
Figure 2-15. Differential Clock Waveform
Figure 2-16. Differential Clock Crosspoint Specification
Crossing
Voltage
Threshold
Region
VH
VL
Overshoot
Undershoot
Ringback
Margin
Rising Edge
Ringback
Falling Edge
Ringback,
BCLK0
BCLK1
Crossing
Voltage
Tp
Tp = T1: BCLK[1:0] period
660 670 680 690 700 710 720 730 740 750 760 770 780 790 800 810 820 830 840 850
200
250
300
350
400
450
500
550
600
650
VHavg (mV)
Crossing Point (mV)
550 mV
250 mV
250 + 0.5 (VHavg - 700)
550 + 0.5 (VHavg - 700)
