Quad-Core Intel® Xeon® Processor 5300 Series Datasheet 97
Thermal Specifications
Table 6-11. Quad-Core Intel® Xeon® Processor L5318 Nominal Thermal Profile
Table 6-12. Quad-Core Intel® Xeon® Processor L5318 Short Term Thermal Profile
6.2.1 Thermal Metrology
The minimum and maximum case temperatures (T
CASE
) are specified in Table 6-1,
through Table 6-7 and are measured at the geometric top center of the processor
integrated heat spreader (IHS). Figure 6-6 illustrates the location where T
CASE
Power (W) T
CASE_MAX
(° C)
P
_PROFILE_MIN
=0 45.0
5 48.4
10 51.8
15 55.2
20 58.6
25 62.0
30 65.4
35 68.8
40 72.2
Power (W) T
CASE_MAX
(° C)
P
_PROFILE_MIN
=0 60.0
5 63.4
10 66.8
15 70.2
20 73.6
25 77.0
30 80.4
35 83.8
40 87.2
