Boxed Processor Specifications
112 Quad-Core Intel® Xeon® Processor 5300 Series Datasheet
Note:
1. The heat sinks and fan assemblies represented in Figure 8-1, Figure 8-2, and Figure 8-3 are for reference
only, and may not represent the final boxed processor heat sinks.
2. The screws, springs, and standoffs will be captive to the heat sink. This image shows all of the components
in an exploded view.
3. It is intended that the CEK spring will ship with the base board and be pre-attached prior to shipping.
Figure 8-2. Boxed Quad-Core Intel® Xeon® Processor 5300 Series 2U Passive Heat Sink
Figure 8-3. 2U Passive Quad-Core Intel® Xeon® Processor 5300 Series Processor
Thermal Solution (Exploded View)
Heat sink
Heat sink standoffs
Heat sink screw
springs
Thermal Interface
Material
Heat sink
screws
Motherboard
and
processor
Chassis pan
Protective Tape
CEK spring
Heat sink
Heat sink standoffs
Heat sink screw
springs
Thermal Interface
Material
Heat sink
screws
Motherboard
and
processor
Chassis pan
Protective Tape
CEK spring
