Electrical Specifications
40 Quad-Core Intel® Xeon® Processor 5300 Series Datasheet
Table 2-15. V
CC
Static and Transient Tolerance for Quad-Core Intel® Xeon® Processor
L5318 Series
Notes:
1. The V
CC_MIN
and V
CC_MAX
loadlines represent static and transient limits. Please see Section 2.13.2 for V
CC
overshoot specifications.
2. This table is intended to aid in reading discrete points on Figure 2-11 for Quad-Core Intel® Xeon®
Processor L5318
3. The loadlines specify voltage limits at the die measured at the VCC_DIE_SENSE and VSS_DIE_SENSE lands
and across the VCC_DIE_SENSE2 and VSS_DIE_SENSE2 lands. Voltage regulation feedback for voltage
regulator circuits must also be taken from processor VCC_DIE_SENSE and VSS_DIE_SENSE lands and
VCC_DIE_SENSE2 and VSS_DIE_SENSE2 lands. Refer to the Voltage Regulator Module (VRM) and
Enterprise Voltage Regulator Down (EVRD) 11.0 Design Guidelines for socket load line guidelines and VR
implementation. Please refer to the appropriate platform design guide for details on VR implementation.
I
CC
(A) V
CC_Max
(V) V
CC_Typ
(V) V
CC_Min
(V) Notes
0 VID - 0.000 VID - 0.015 VID - 0.030 1,2,3
5 VID - 0.005 VID - 0.020 VID - 0.035 1,2,3
10 VID - 0.010 VID - 0.025 VID - 0.040 1,2,3
15 VID - 0.015 VID - 0.030 VID - 0.045 1,2,3
20 VID - 0.020 VID - 0.035 VID - 0.050 1,2,3
25 VID - 0.025 VID - 0.040 VID - 0.055 1,2,3
30 VID - 0.030 VID - 0.045 VID - 0.060 1,2,3
35 VID - 0.035 VID - 0.050 VID - 0.065 1,2,3
40 VID - 0.040 VID - 0.055 VID - 0.070 1,2,3
45 VID - 0.045 VID - 0.060 VID - 0.075 1,2,3
50 VID - 0.050 VID - 0.065 VID - 0.080 1,2,3
55 VID - 0.055 VID - 0.070 VID - 0.085 1,2,3
60 VID - 0.060 VID - 0.075 VID - 0.090 1,2,3
