Intellian v150NX User Manual

15
Planning Installation
Min. 15 mm (0.59") Max. 25 mm (0.98")
1000 mm (39.37")
247.5 mm (9.74")
247.5 mm (9.74")
Ø650 mm (25.59")
Ø650 mm (25.59")
Ø300 mm (11.81")
350 mm (13.78")
10 mm (0.39")
170 mm
(6.69")
50 mm (1.97
")
50 mm (1.97
")
30 mm
(1.18")
180 mm
(7.09")
180 mm
(7.09")
200 mm
(7.87")
220 mm
(8.66")
42 mm (1.65")
280 mm (11.02")
Ø22 mm (0.87"
)
Ø22 mm
(0.87")
45°
160 mm
(6.30")
50 mm
(1.97")
280 mm
(11.02")
180 mm
(7.09")
10 mm (0.39")
4-Ø14 mm (0.55") Holes
Figure: Recommended Size of Mast
BOW
Direction
Mast Designing (Installation Example)
The ADU mast must be designed to carry the weight of the ADU unit. The mast must also be able to withstand
on-board vibrations and wind speeds on the radome.
When Placing Cable Outside Mast
