Specification
Antenna System
Size
Antenna Radome Height 1970 mm (77.56")
Antenna Radome Diameter Ø1900 mm (74.80")
Antenna Reector Diameter Ø1500 mm (59.06")
A/C Frame Height 652 mm (25.67")
A/C Frame Diameter Ø1900 mm (74.80")
Weight
Antenna < 300 kg (661.4 lbs)
Radome < 80 kg (176.4 lbs)
A/C Frame < 230 kg (507.1 lbs)
Platform Three Axis: Azimuth, Elevation, Cross-level
Positioning
3-axis Velocity Mode Servo Control: Azimuth, Elevation,
Cross-Level
Pedestal Motion
Range
Azimuth Unlimited
Elevation -15° to +110°
Cross-level Up to ± 35º
Pointing Stabilization Accuracy 0.2° max in presence of specied ship motions
Ship Motions
Roll ± 25° at 6 second
Pitch ± 15° at 6 second
Yaw ± 8° at 6 second
Turning rate 10°/sec
RX
Frequency 10.7 ~ 12.75 GHz Ku-band
Gain 43.5 dBi @ 11.7 GHz
G/T over Rx Range > 22.5 dB/K @ 12.75 GHz, 30˚ EL, with radome
Tx
Frequency 13.75 ~ 14.5 GHz Ku-band
Gain 45.0 dBi @ 14.25 GHz
Above Deck IFL Termination
1 x 50 Ohm N-type female connector
TX/RX: 10 MHz / 50 MHz / 400 MHz / 433 MHz /
L-band (950 - 2150 MHz)
DC power to BUC & pedestal (and LNB)
Polarization Linear polarization
BUC 40 W (standard), 16 W / 100 W (optional)
LNB Intellian PLL LNB
Antenna Control Unit (ACU)
ACU Size 431 mm x 350 mm x 44.3 mm
ACU Weight 5.2 kg
Display 128 X 64 Graphic OLED (White)
Key 2 button (Direction Key)
LED Indicator 3 LEDs for Power, Tracking, Error
USB Port 2 ea (front panel), 1 ea (rear panel, for Wi-Fi dongle)
Ship’s Gyrocompass Interface NMEA 2000 / NMEA 0183
GPS Interface NMEA Out
