Intellian v150NX - Diagnosis and Information

56
Operating ACU
SNR F:12.490/11.300 RX:H TX:V
TRACKING 062.2 E
HDG:120.4
GPS:
P
Executes antenna Diagnosis test and shows the real-time diagnosis result.
Diagnosis
DIAGNOSIS
DIAG ALL
DIAG : CODE 101
1 - - - O O 7 O O 10
- O 13 14 O O
Press
Move Key
Press
Select Key
Refer to the diagnosis codes for the test results.
DIAG : CODE 101
1 - - - O O 7 O O 10
- O 13 14 O O
2
1
ü Main Display
ü Diagnosis Display
ü Diagnosis Result Display
