Intellian v150NX User Manual

40
Operating Install Wizard
Operating Install Wizard
Turning On System
Make sure the antenna has a clear view of the sky. Press the Power button on the front of the Antenna Control
Unit (ACU) then a wait few minutes for system startup. Once the antenna nds the satellite, the "POWER"
status lights will be lit Green.
Accessing AptusNX
The network is automatically congured by DHCP without the need for additional PC IP conguration.
1. Connect an Ethernet cable from the Management LAN port on the front of the ACU to the LAN port of PC.
2. The network connection is established automatically.
3. Use the following IP address to access Intellian AptusNX page.
• IP Address: 192.168.2.1 (Default)
Management LAN Port
ACU - Front Panel
Figure: Front Panel Management LAN Port Connection
PC
(Not supplied)
