Technical Specification
Technical Specification
General
Approvals
CE – conforms to EU Directive 89/336/EEC
FCC – verified to CFR47: Part 15
Dimensions
Satellite antenna unit 78.0 cm x 84.5 cm (30.7” x 33.3”)
Antenna dish diameter 60cm (23.6”)
Antenna control unit 43.1cm x 38.1cm x 4.4cm (17” x 15” x 1.7”)
Weight
Satellite antenna unit 59.5 kg (131.2 lbs)
Antenna control unit 5.2kg (11.5 lbs)
Antenna system performance
Tx Frequency 14.0 ~ 14.5 GHz Ku-band
Tx Gain 38.1 dBi
Rx Frequency 10.95 ~ 12.75 GHz Ku-band
Rx Gain 35.8 dBi
Polarized Feed Cross-pol / Cross-pol & Co-pol
Skew Control Automatic Skew-angle Control
Azimuth range Unlimited
Elevation range -10° ~ +100°
Cross-level range ±30°
Stabilization Accuracy 0.2° peak mis-pointing @ max ship motion condition
Max Ship’s motion ±25°roll, ±15° pitch, ±8°yaw@ 6 sec
Turning rate Up to 12°/ sec & 5°/ sec2
BUC 4W, 6W, 8W (optional)
Rack Mount Antenna Control Unit
Display 2 Line 40 Character Graphic VFD Module
Serial Interface 19200 bps 8, N, 1, RS-232C
Modem Interface Ethernet port / RS-232C / I/O ports
Remote Access TCP / IP
Input Power 100 ~ 240V AC, 50 ~ 60Hz
Gyrocompass Interface NMEA / Syncro
