Intellian V60 User Manual

67
OPERATING THE ACU
Set Modem Port
System menu
Modem port menu
Set Mediator &
modem port
Setup mode
SETUP MODE ?
YES NO
1. Press LEFT arrow key to move cursor to YES and press OK key to enter SETUP mode.
+ANTENNA + SATELLITE
+S YSTEM +INSTALLATION
2. Press DOWN arrow key to move cursor to SYSTEM menu and press OK key to enter it.
+SET LOCAL +SE T LOCATION
+M ODEM PORT +BACKUP& RESTORE
3. Press DOWN arrow keys to move cursor to COM. PORT menu and press OK key to enter
it.
USE MEDIAT OR MODEM PORT
YES ETHERNET
4. USE MEDIATOR is to enable the usage of MEDIATOR if the antenna is connected to the
Intellian dual VSAT Mediator.
NOTE: USE MEDIATOR must be disabled if there is no MEDIATOR connected to the ACU. Improper
setting of this parameter will cause your ACU’s modem interface working incorrectly.
MODEM PORT* is to select a proper data communication port on the ACU to interface with
the satellite modem.
MODEM PORT*
ETHERNET
RS422
RS232
