65
OPERATING THE ACU
Set Location
System menu
Set location menu
Gyro type and
Baud rate
Setup mode
SETUP MODE ?
YES NO
1. Press LEFT arrow key to move cursor to YES and press OK key to enter SETUP mode.
+ANTENNA + SATELLITE
+S YSTEM +INSTALLATION
2. Press DOWN arrow key to move cursor to SYSTEM and press OK key to enter it.
+SET L OCAL +SET LOCATION
+MODEM POR T +BACKUP& RESTORE
3. Press RIGHT arrow key to move cursor to SET LOCATION and press OK key to enter it.
GY RO TYPE B AUD RATE
NM EA
4800
4. Set the ship’s GYRO TYPE* and BAUD RATE
A search pattern 1 or 3 will be initiated according to which GYRO TYPE is selected and the
existence of the gyro input. Set the BAUD RATE as 4800,9600,19200 or 38400 according to
your device.
A search pattern 1 will be initiated automatically if the gyro input does not exist and the gyro
type is selected other than GROUND TEST.
NOTE: The bow offset will not be saved automatically if Search 1 pattern is initiated. In this case, the
antenna will need to re target the desired satellite using Search 1 every time if the antenna restarts.
Gyro search type
Setting of Heading Device
Existence of Heading
Data
No Device
NMEA/
Synchro
Ground
Test
w/ Heading Data
Search 1 Search 3 Search 3
w/out Heading Data
Search 1 Search 1 Search 3
GYRO TYPE*
NO DEVICE
NMEA
SYNCHRO
GROUND TEST
To Next Page
