Intellian V60 User Manual

37
INSTALLING THE ACU
ACU Connector Guide
• Console Port
NOTE: NMEA GPS IN/OUT Sentence: GPGLL (4800 Baud, 8, N, 1)
12345
6789
54321
9876
Pin Signal Pin Signal
1
GND
6
GPS OUT -
2
GPS OUT +
7
MODEM_SIGNAL_IN
3
MODEM_LOCK
8
MODEM_CTRL2
4
MODEM_CTRL1 (TX MUTE)
9
GPS IN -
5
GPS IN +
ACU Console Port
D-Sub 9 pin Female
D-Sub 9 pin Male connector
Supplied Component
12345
6789
54321
9876
12345
6789
12345
6789
Pin Signal Pin Signal
1
-
6
-
2
-
7
-
3
SYNCHRO_R2
8
SYNCHRO_R1
4
SYNCHRO_R3
9
SYNCHRO_S2
5
SYNCHRO_S1
Pin Signal Pin Signal
1
-
6
-
2
RXD
7
-
3
TXD
8
-
4
-
9
-
5
GND
Pin Signal Pin Signal
1
-
6
-
2
RXD +
7
RXD -
3
TXD +
8
TXD -
4
-
9
-
5
GND
ACU Synchro Port
D-Sub 9 pin Female
D-Sub 9 pin RS232
Connector
D-Sub 9 pin Male connector
Supplied Component
D-Sub 9 pin RS422
Connector
• Synchro Connector
• RS232 / 422 Connector (Modem & BUC Interface)
