75
PC CONTROLLER SOFTWARE
• Enable the Usage of External Lock & TX Mute
- Connect a RJ45 cable from the Ethernet connector on the ACU to the modem or
connect a 9 pin serial cable from the RS232/422 connector on the ACU to the
modem.
- Select a proper data communication port (RS232/422 / Ethernet) to interface with
a modem.
- Select a proper communication protocol (I/O Console / OpenAMIP / Serial GPS)
to interface with a modem.
- Enable / disable the usage of TX MUTE function.
- TX Mute is a transmit inhibit output from the ACU to disable/mute the modem
transmit through a 5 V (HIGH) or 0 V (LOW) current whenever the antenna is
blocked, searching, or is mis-pointed 0.5 degrees from peak satellite position.
This item will only be activated when the modem protocol is set as I/O Console.
- Enable/disable the usage of External Lock function. This function will only be
activated when the modem protocol is set as I/O Console.
- Modem Lock is referred that modem lock output from the modem provides a logic
input through a 5 V (HIGH) or 0 V (LOW). current to the ACU to identify when it is
on the correct satellite. This item will only be activated when the modem protocol
is set as I/O Console.
• Select GPS Out Sentence Type
- Select GPS OUT SENTENCE type (GPGLL / GPGGA / Simple GPGGA)
