v60 – Marine Satellite Communication System
36
Connecting the System without a Ship’s Gyro
For a vessel where the ship’s gyro compass is not installed or is difficult to be
connected, the Intellian Gyro-Free satellite search function will be automatically
enabled to allow the antenna to lock onto the desired satellite without requiring an
external heading input.
The table below provides an example of the Gyro-Free satellite search algorithm.
The Search 1 or Search 3 satellite search pattern will be triggered according to the
existence of heading input and the setting of the heading device.
Search 1: The antenna will search for the target satellite by turning its azimuth
angle in CCW direction until the antenna receives the lock signal from the
modem or the DVB transponder of the target satellite is decoded by the
antenna.
Search 3: The antenna will search for the target satellite by turning its azimuth angle
directly to the position calculated using the ship’s heading input and lock
onto the satellite.
Quick Setup Procedure
• Set the satellite having DVB transponder as the target satellite.
• Set “No Device” to the heading device.
• The antenna will search for the target satellite by turning its azimuth angle in CCW
direction and lock onto the satellite signal until the antenna receives a lock signal
from the modem or the DVB transponder of the target satellite is decoded.
• Set the heading device as NMEA / Synchro
• Enter “Manual search” menu and press “Function” key to save the current settings.
Intellian ACU will automatically calculate and save the BOW offset.
• Upload the real TARGET satellite pre-configured from the library.
Setting of Heading Device
Existence of Heading Data No Device NMEA/Synchro Ground Test
w/ Heading Data
Search 1 Search 3 Search 3
w/out Heading Data
Search 1 Search 1 Search 3
To Next Page
