INSTALLING THE ANTENNA
System Cables
Before installing the system cables, you need to take the following points into
consideration.
1. All cables need to be well clamped and protected from physical damage and
exposure to heat and humility.
2. Cable with an acute bend is not allowed.
3. Where a cable passes through an exposed bulkhead or deck head, a watertight
gland or swan neck tube should be used.
• RF Cable (Customer Furnished)
Due to the voltage losses across the length of the RF coaxes at L-Band, Intellian
recommends the following 50 ohm coax cable types for standard system installations.
For cable runs longer than 120 meters, please consult Intellian Technologies.
Intellian provides a N to F type adapter to connect 75 ohm coaxial cables.
Run Length Coaxial Cable Type
Up to 30 meters LMR-300-50
Up to 70 meters LMR-400-50
Up to 120 meters LMR-600-50
Recommended
RF Cables
Power Requirement
Intellian v60 has been designed to work on a vessel’s power supply rated at 100-
240 V AC.
• BUC Power Cable
Cable Length mm
2
per conductor
Up to 30 meters 1.25 mm
2
Up to 50 meters 2.30 mm
2
Up to 70 meters 3.00 mm
2
Up to 120 meters 5.00 mm
2
Recommended
BUC Power Cables
Type Multi-conductor, Shielded
Number of wires 5 conductors for Synchro
2 conductors for NMEA
• Gyro Compass / GPS Interface Cable (Customer Furnished)
