31
INSTALLING THE ANTENNA
Position the Radome
The radome should be positioned with the BOW marker aligned as close as possible
to the ship’s centerline.
Recommended size of the
support pedestal
100~150 cm (40~60”)
Base Panel
0.8 cm (0.3”)
Supporting Pole
Appr Ø10 cm (3.9”)
