v60 – Marine Satellite Communication System
48
Search 3 range
Search 1 range
Search Parameters
Setup mode
Manual search menu
Antenna menu
Search param
SETUP MODE ?
YES NO
1. Press LEFT arrow key to move cursor to YES and press OK key to enter SETUP mode.
+ANTENNA +SATELLITE
+SYSTEM +INSTALLATION
2. Press OK key to enter ANTENNA menu.
+MANU AL SEARCH + S ET POL ANGLE
+SEARCH PARAM +SET PARA METERS
3. Press arrow keys to move cursor to SEARCH PARAM menu and press OK key to enter it.
SEARCH WAIT TI ME INC REMENT STEP
030 0.50
SEARCH1 AZ SEARCH 1 EL
400 06
SEARCH3 AZ SEARCH 3 EL
003 04
4. Set SEARCH 1 and 3 AZ (Azimuth) range and EL (Elevation) range. SEARCH 2 is reserved
for future use.
A search pattern 1 or 3 will be initiated according to which GYRO TYPE is selected
and the existence of the gyro input.
Search 1: a search pattern 1 will automatically be initiated when the ship’s heading
input does not exist / is failed. The antenna will go to the relative azimuth position
0º at the calculated elevation and search in the azimuth CCW direction and search
up +0.5º & down -0.5º with a total 6º(±3º) in elevation. The search cycle will repeat
until the antenna receives the lock signal from the modem or the DVB transponder
of the target satellite is decoded by the antenna. If the desired signal is found and
above the predefined detect level, the ACU will enter to Search 3. However, the
antenna will not initiate Search 3 pattern but go into TRACKING mode immediately
if the desired signal is above the predefined tracking threshold level. If the detected
signal is below the predefined tracking threshold level, the search 1 will repeat and
start 3º away from the current position.
