Tracking & Heading
information
Power status
Antenna & ACU
versions
NBD F: 1247000 BW:1 000 SIG:301
004.5 3E 52.22N HDG:090.0 L: 10000 Fn
5. NBD, GPS and ship’s heading information are shown.
- NBD (Narrow Band Detection) IF tracking frequency: 1247000 kHz
- Detected Band Width: 1000 kHz
- SIG (Signal Level ): 301 (When NBD mode for tracking signal is chosen)
- W (West ) / E (East) Longitude: 4.53º E
- N (North) / S (South) Latitude: 52.22º N
- HDG (Ship’s Heading): 90º
- LNB local oscillator (LO) frequency: 10000 MHz
[PW R] ANT: 2 6.4V LNB: 13V + 0KHZ
ACU: 2 7.1V [POL] TX:V RX :H
6. Press RIGHT arrow key to display the current operation voltage for antenna, ACU and
LNB. POL indicates the TX polarity (VERTICAL) and RX polarity (HORIZONTAL).
V1- 60-03H ANT. SERIAL 1.00
VP-T1 00 ACU SERIAL 1.00(1.00)
7. Press RIGHT arrow key to display the below information.
- Antenna part number, antenna serial number and PCU firmware version.
- ACU part number, ACU serial number, ACU firmware version and Library version.
Press RETURN Key to return to the first page of the antenna current status.
