Working with ENG: EO425 Page 26
ENG/DLB Instruction for Use - English
Date: 2011-09-27 Page 26
3-channel left vertical
Figure 1.9: Left Binocular setup
After you have applied the electrodes you need to let the electrodes “adjust to patient” for some
minutes. It is different from patient to patient how much time it takes to adjust. You may experience
signal drift in the first 5-10 minutes after the electrodes have been applied.
Configure electrode montage
Included in the “Configure Test” tabs for the various tests, you can select which electrode montage
you will use for the testing.
Figure 1.10 Electrode montage
