CS3000, Users
Rev A, January, 2011
Page 22 of 35
16. The display shows “HH-04”. Press the Mode button. The display will show “00000”
with the far right number flashing. The flashing digit may be incremented by
pressing the Lb/Kg button or decremented by pressing the ZERO button. To move
one digit to the left, press the TARE button. Enter the value of the forth load and
press the Mode button when the value of the forth load is displayed.
17. The display shows “LL-04”. Apply the forth load to the scale. With the forth load
applied to the scale press Mode button.
Repeat step 10 and 11 for each additional “HH-05” – “HH10” and “LL-05”- “HH10”
combination. If the scale is turned off at any time, the calibration data acquired to that
point will be retained. After the Mode button is pressed after “LL-10”, the display will
return to normal weighing.
Finished
Following calibration, insert the allen wrench and press the cal enable switch to disable
calibration. Using a ¼” Allen wrench, replace the access plug and apply a calibration
sticker to cover the access plug.
Calibration (Verify)
NOTE: The stated accuracy specifications are based on the graduation setting in
the table below. If the graduation setting is set other than the value in the table
below the accuracy specification remains with the graduation size listed below.
If your capacity is: Set your graduation to:
500 lb / 250 kg 0.2 lb / 0.1 kg (8)
2000 lb / 1000 kg 1 lb / 0.5 kg (6)
5000 lb / 2500 kg 1 lb / 0.5 kg (6)
10000 lb / 5000 kg 2 lb / 1 kg (5)
20000 lb / 10000 kg 5 lb / 2 kg (4)
30000 lb / 10000 kg 10 lb / 5 kg (3)
50000 lb / 25000 kg 10 lb / 5 kg (3)
70000 lb / 35000 kg 20 lb / 10 kg (2)
100,000 lb / 45000 kg 20 lb / 10 kg (2)
To verify that the scale has maintained its calibration points, load the scale at 10%
increments and ensure that the display indicates an accuracy of 1% of the load or one
display division as indicated in the table above. After all 10 points have been verified the
scale is complete.
