CS3000, Users
Rev A, January, 2011
Page 34 of 35
Parts List: 20K lb, 30K lb capacity
Item # QTY Part # Description
1 1 000072 control harness
2 6 250095 button cover
3 12 --- .375-16 screw
4 1 250492 keypad overlay
5 1 250090 logo overlay
6 1 502575 CS3000 display end
7 1 250095 window overlay
8 1 220063 4-pin MTA
9 4 --- .25-20 set screw
10 1 000073
000063
loadcell (20K capacity CS3000)
loadcell (30K capacity CS3000)
11 1 insert
12 1 505483 display window
13 1 601051 1-8 locking nut
14 1 500813 top loadcell adapter
15 2 602008 1-8 bolt
16 1 500824 loadcell housing
17 1 500710 retaining ring gasket
18 1 500709 top retaining ring
19 1 601039 eye nut
20 2 --- .25-20 screw
21 2 --- .25-20 screw
22 2 500805 housing gasket
23 1 550153 end plate
24 1 500946 lower loadcell adapter
25 2 500707 battery tube
26 20 --- 6-32 screw
27 4 330042 battery spring
28 2 500706 battery plate
29 2 500705 battery cap
30 2 --- 8-32 screw
31 2 500708 battery tube end
32 2 601047 wing nut
33 1 000075 battery harness assembly
35 1 603063
603038
swivel hook assembly (20K)
swivel hook assembly (30K)
37 16 601014 .031 nylon washer
38 4 601032 6-32 m/f standoff
39 4 601002 6-32 nut
40 2 500808 board mount
41 4 601310 vibration mount
42 1 000980 CS3000 Circuit Card assembly
43 4 601015 .062 nylon washer
44 4 --- 8-32 screw
45 4 601315 6-32 standoff
48 4 600015 8-32 unc screw
49 1 500803 lower retaining ring
50 2 500818 bellows
51 1 820027 hose clamp
