Intercomp CS3000 - Parts List: 5 K Lb, 10 K Lb Capacity

CS3000, Users
Rev A, January, 2011
Page 32 of 35
See the following page for parts list
Parts List: 5K lb, 10K lb capacity
Item # QTY Part # Description
1 1 000072 control harness
2 6 250058 button cover
3 12 --- .375-16 screw
4 1 250492 keypad overlay
5 1 250090 logo overlay
6 1 502575 CS3000 display end
7 1 250005-B window overlay
8 1 220063 4-pin MTA
9 4 -- .25-20 set screw
10 1 000073 loadcell (5K and 10K capacity CS5000)
11 1 insert
12 1 505483 display window
13 1 500740 loadcell threaded adapter
14 1 500984 loadcell housing
15 1 500710 retaining ring gasket
16 1 505482 top retaining ring
17 2 --- .25-20 screw
18 2 --- .25-20 screw
19 1 500754 eye nut
20 2 500805 housing gasket
21 1 550153 End plate
22 2 502627 battery tube
23 20 --- 6-32 screw
24 4 330042 battery spring
25 2 500706 battery plate
26 2 500705 battery cap
27 2 --- 8-32 screw
28 2 500708-B battery tube end
29 2 --- wing nut
30 1 000075 battery harness assembly
31 1 500791 assembly screw
32 1 500791 swivel hook assembly
33 1 500791 assembly nut
34 16 --- .031 nylon washer
35 4 601315 6-32 m/f standoff
36 4 601002 6-32 nut
37 2 500807-B board mount
38 4 601310 vibration mount
39 1 000980 CS3000 circuit board assembly
40 4 --- 8-32 screw
41 4 600015 8-32 unc screw
42 1 500803 lower retaining ring
43 2 500818 bellows
44 1 820027 hose clamp
