Intercomp CS3000 - Physical Specifications; Dimensions and Capacities

CS3000, Users
Rev A, January, 2011
Page 5 of 35
Physical
Capacity Graduation
A B C D Hook Eye nut
or
shackle
Approx
Weight
500 lb
250 kg
0.2 lb
0.1 kg
in:
mm:
19.3
490
3.06
77.7
1.44
35.1
1.41
35.8
C/L 3 ton
S1 swivel
C/L #7
eye nut
48 lb
22 kg
2,000 lb
1,000 kg
1 lb
0.5 kg
in:
mm:
19.3
490
3.06
77.7
1.44
35.1
1.41
35.8
C/L 3 ton
S1 swivel
C/L #7
eye nut
50 lb
23 kg
5,000 lb
2,500 kg
1 lb
0.5 kg
in:
mm:
22.0
558
3.06
77.7
1.82
44.5
1.69
42.9
C/L 5 ton
S1 swivel
C/L #7
eye nut
58 lb
26 kg
10,000 lb
5,000 kg
2 lb
1 kg
in:
mm:
22.0
558
3.06
7.77
1.75
44.5
1.69
42.9
C/L 5 ton
S1 swivel
C/L #7
eye nut
58 lb
26 kg
20,000 lb
10,000 kg
5 lb
2 kg
in:
mm:
37.15
944
6.25
159
2.60
65.8
2.41
61.2
C/L 10 ton
S1 swivel
C/L # 11
eye nut
97 lb
44 kg
30,000 lb
15,000 kg
10 lb
5 kg
in:
mm:
39.15
994
6.25
159
3.00
76.2
3.19
81.3
The
dimensions
below are
top to
bottom
shackle,
eye to eye
on 25-50
ton / 12.5 –
25 metric
ton models
C/L 15 ton
S1 swivel
C/L # 11
eye nut
122 lb
55 kg
50,000 lb
25,000 kg
10 lb
5 kg
in:
mm:
43.5
1105
6.00
152
3.66
93.0
3.62
92.0
17.0
432
C/L 25 ton
S1 swivel
C/L 40 ton
#2140
220 lb
100 kg
70,000 lb
35,000 kg
20 lb
10 kg
in:
mm:
48.6
1234
6.00
152
4.56
116
3.75
92.3
17.0
432
C/L 35 ton
S1 swivel
C/L 40 ton
#2140
248 lb
113 kg
100,000 lb
50,00 kg
20 lb
10 kg
in:
mm:
56.0
1422
7.75
197
5.06
129
4.25
108
18.0
457
C/L 45 ton
S1 swivel
C/L 50 ton
#2140
392 lb
178 kg
*
*
*
*
