CS3000, Users
Rev A, January, 2011
Page 30 of 35
Parts List: 2K lb capacity
Item # QTY Part # Description
1 1 000072 control harness
2 6 250058 button cover
3 12 --- .375-16 screw
4 1 250089 keypad overlay
5 1 250090 logo overlay
6 1 500804 CS3000 display end
7 1 250095 window overlay
8 1 220063 4-pin MTA
9 4 --- .25-20 set screw
10 1 000062 loadcell (2K capacity CS3000)
11 1 insert
12 1 500817 display window
13 1 500838 loadcell threaded adapter
14 1 500739 loadcell retainer
15 1 500824 loadcell housing
16 1 500710 retaining ring gasket
17 1 500709 top retaining ring
18 1 500713 retaining ring spacer
19 2 --- .25-20 screw
20 2 --- .25-20 screw
21 1 601039 eye nut
22 2 500805 housing gasket
23 1 550153 end plate
24 2 500707 battery tube
25 20 --- 6-32 screw
26 4 330042 battery spring
27 2 500706 battery plate
28 2 500705 battery cap
29 2 --- 8-32 screw
30 2 500708 battery tube end
31 2 601047 wing nut
32 1 000075 battery harness assembly
34 1 603035 swivel hook assembly
36 16 601014 .031 nylon washer
37 4 601032 6-32 m/f standoff
38 4 601002 6-32 nut
39 2 500808 board mount
40 4 601028 vibration mount
41 1 000980 CS3000 circuit board assembly
42 4 601015 .062 nylon washer
43 4 --- 8-32 screw
44 4 601018 6-32 standoff
47 4 --- 8-32 unc screw
48 1 500803 lower retaining ring
49 2 500818 bellows
50 1 820027 hose clamp
