Mode Menu
Press the mode button to access the Mode menu. The display will show “Print". If it
shows “StEP”, then the calibration button needs to be pressed to return to normal RUN
mode, which will allow entry into the Mode Menu when mode is pressed again. (Or
enter ‘5’ for the “StEP” entry which will bring you to this Mode Menu.)
At times it will be necessary to enter up to a five digit number. When this is necessary
the current number will be displayed with the right most digit flashing. The flashing digit
may be incremented by pressing the Lb/Kg button or decremented by pressing the
ZERO button. To move one digit to the left, press the TARE button. When you have
finished entering a number, press the Mode button. The settings are saved every time
Mode is pressed to advance the menu, and the scale can then be turned off.
Step Function Note
Default
Print
Print Yes or no
no
b.LitE
Back light On, off, or Auto
Auto
SEtP1
Set Point 1 0 to 19999
199999
SEtP2
Set Point 2 0 to 19999
199999
vEr.
Firmware Version View only XXXXX
A. rt
Average rate 1 to 120
004
A.tHrS
Average Threshold 1 to 10000
00000
A off
Auto off 000 = off, 1 to 240
060
Prt t
Print Mode 0 = On-demand, 1 = Continuous
0
Pbaud
Printer baud rate 1200, 2400, 4800, 9600, 19200,
38400, 57600, or 115200
9600
SC id
Scale ID 1-190
001
SCLS
Number of scales 1-32
01
Proto
Protocol
StAnd, Lo Pr, C.L00P, or none Lo Pr
i.baud
RS485 Interface baud
rate
9600 or 115200
9600
radio
Radio Enable Yes or no
yES
Rf CH
Radio Channel 01 to 12
01
Rf.pan
Radio Network ID 0 to 65534
8000
Rf.eCp
Radio encryption enable Yes or no
no
Radio Encryption Key 0 to 65534
00000
Rf.def
Restore Radio Defaults 0 or 3
0
Setting the Mode Menu Parameters
