Intermec EasyCoder C4—User’s Guide 41
Appendix B— Media Specifi cations
Tags and Strip with Slots
← a → Tag or strip width:
Maximum: 116.0 mm (4.57 inches)
Minimum: 25.0 mm (1.00 inches)
← b → Tag length:
Minimum: 6.35 mm (0.25 inches)
← c → Detection slot width:
Minimum: 14 mm (0.55 inches)
← d → Detection slot height:
Maximum: 10 mm (0.39 inches)
Minimum: 1 mm (0.08 inches)
The label gap sensor is offset 4.5 mm (0.177 inches) to the right of the center of the
media path.
a
c
TICKETS,TAGS, &
CONTINUOUS STRIP
d
b
