Chapter 4 — Configure the Printer
92 PC23 and PC43 Desktop Printer User Manual
About Printer Configuration
Configuration settings determine how the printer operates. To view
and change printer settings, you can:
• use a browser to view the printer web page through your network
connection. You need to know the printer IP address for this
method.
• use the LCD printer Main Menu.
• use an application such as Intermec PrintSet to communicate with
the printer through a network, serial, or USB connection.
Configure the Printer From the Main Menu
You can view and change settings directly on the printer through the
Settings menu.
1 In the Main Menu, use to select Settings and press . The
Settings menu appears with Communications selected.
Setting Type Description
Communications All communications and network settings:
• Serial (appears when using serial connection to PC)
• Ethernet (appears when Ethernet module is
installed)
• Wireless 802.11 (appears when Wi-Fi/Bluetooth
module is installed)
• Bluetooth (appears when Wi-Fi/Bluetooth module
is installed)
Settings
Communications
Printing
System Settings
Network Services

Intermec PC23d Specifications

General

Color	-
Print technology	Direct thermal
Maximum resolution	203 x 203 DPI
Maximum print height	- mm
Maximum printing width	56 mm
Plug and Play	Yes
Sustainability certificates	ENERGY STAR
Certification	CE, RoHS
Internal memory	128 MB
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
AC adapter output current	2.5 A
AC adapter output voltage	24 V
Display	LCD
Product color	White
Operating temperature (T-T)	5 - 40 °C
Operating relative humidity (H-H)	10 - 80 %
USB 2.0 ports quantity	2
Connectivity technology	Wired
Quantity per pack	1 pc(s)
Maximum label width	60 mm
Maximum label length	1727 m
Maximum roll diameter	127 mm
Supported paper width	15 - 60 mm

Weight and Dimensions

Depth	215 mm
Width	125 mm
Height	177 mm
Weight	1450 g
