Chapter 2 — Set Up the Printer
50 PC23 and PC43 Desktop Printer User Manual
Load Ribbon
1 Press the printer latches toward the front of the printer and open
the printer lid.
2 If there is an empty ribbon core in the media compartment, remove
the core and set it aside.
3 Remove and discard the full ribbon takeup core.
Recommended Feed Adjust Values for PC43t
Setting 203 dpi 300 dpi Distance
Start Adjust -125 -185 -15.7 mm (-0.62 in)
Stop Adjust 16 24 2.1 mm (0.08 in)
Note: You may need to adjust the recommended values slightly
depending on your media type, supply method, and roll sizes, or
because of individual differences between printers.
