Intermec PC23d User Manual

Appendix A — Specifications and Default Settings
156 PC23 and PC43 Desktop Printer User Manual
Wireless 802.11 Security Settings
This section describes the 802.11 security settings. To view these
settings:
• From the printer Main Menu, select Settings > Communications
> Wireless 802.11 > Security.
• From the printer web page, click the Configure tab >
Communications > Wireless 802.11.
Setting Description Default
Security Type Selects the protocol the radio uses to verify its identity
and makes sure that it is authorized to communicate on
the wireless network.
None
Association Selects the security method that the radio uses to get
access to the wireless network.
Open/WEP
Pre-Shared Key Defines the passphrase that allows the radio to
authenticate over the wireless network (for both WPA and
WPA2 security). Range is 8 to 64 characters.
None
Network Key Index Selects the active network key to use for WEP security.
Range is 1 to 4.
1
Network Key 1,
Network Key 2,
Network Key 3,
Network Key 4
Defines a network key that is used for WEP security. Keys
are entered in ASCII or hexadecimal (preceded by 0x)
format.
Empty string
User Name Sets the name that the printer uses when logging in to the
network. Range is 1 to 96 characters.
None
Password Sets the password that the printer uses when logging in to
the network. Range is 1 to 96 characters.
None
Anonymous Name Sets the outer EAP user name that the printer uses for
logging in to the network. Maximum length is 96
characters.
Empty string
Inner
Authentication
Selects the authentication method that is used when the
EAP type is EAP-FAST, PEAP, or TTLS.
MSCHAPv2
CA Certificate Sets the name of the Certificate Authority (CA) that
verifies the server certificate. This CA should be the same
one that was used to sign the server certificate.
intermec.pem
Client Certificate Sets the name of the client certificate the printer uses to
authenticate to the network using EAP-TLS. Maximum
length is 128 characters.
None

Intermec PC23d Specifications

General

Color	-
Print technology	Direct thermal
Maximum resolution	203 x 203 DPI
Maximum print height	- mm
Maximum printing width	56 mm
Plug and Play	Yes
Sustainability certificates	ENERGY STAR
Certification	CE, RoHS
Internal memory	128 MB
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
AC adapter output current	2.5 A
AC adapter output voltage	24 V
Display	LCD
Product color	White
Operating temperature (T-T)	5 - 40 °C
Operating relative humidity (H-H)	10 - 80 %
USB 2.0 ports quantity	2
Connectivity technology	Wired
Quantity per pack	1 pc(s)
Maximum label width	60 mm
Maximum label length	1727 m
Maximum roll diameter	127 mm
Supported paper width	15 - 60 mm

Weight and Dimensions

Depth	215 mm
Width	125 mm
Height	177 mm
Weight	1450 g
