Intermec PC23d User Manual

Chapter 2 — Set Up the Printer
PC23 and PC43 Desktop Printer User Manual 59
Print Configuration Labels from the Main Menu
For quick reference, you can print configuration information,
including lists of the fonts, images, and applications installed on the
printer.
1 In the Ready screen, press . The Main Menu appears.
2 Press to select Tools and then press . The Tools menu appears
with Test Labels selected.
3 Press . The Test Labels menu appears.
4 Press to select a Printer Information or Printer Settings and then
press . A list of available labels appears.
5 Press . The configuration label prints.
Configuration Labels
This section describes configuration label information. A typical
configuration label looks like this:
Test Labels
Print Quality
Resources
Printer Information
Printer Settings

Intermec PC23d Specifications

General

Color	-
Print technology	Direct thermal
Maximum resolution	203 x 203 DPI
Maximum print height	- mm
Maximum printing width	56 mm
Plug and Play	Yes
Sustainability certificates	ENERGY STAR
Certification	CE, RoHS
Internal memory	128 MB
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
AC adapter output current	2.5 A
AC adapter output voltage	24 V
Display	LCD
Product color	White
Operating temperature (T-T)	5 - 40 °C
Operating relative humidity (H-H)	10 - 80 %
USB 2.0 ports quantity	2
Connectivity technology	Wired
Quantity per pack	1 pc(s)
Maximum label width	60 mm
Maximum label length	1727 m
Maximum roll diameter	127 mm
Supported paper width	15 - 60 mm

Weight and Dimensions

Depth	215 mm
Width	125 mm
Height	177 mm
Weight	1450 g
