Chapter 6 — Maintain the Printer
126 PC23 and PC43 Desktop Printer User Manual
5 Disconnect the cable from the printhead and remove the printhead
from the printer.
6 Connect the ribbon cable to the new printhead.
7 Slide the printhead into the holders in the print mechanism.
8 Press the printhead onto the locator pins in the mechanism.
9 Tilt the printhead up into the printer lid and press it into place.
When the printhead is in the correct position, the printhead latches
snap into place on the sides of the printhead.
10 For a thermal transfer printer, install the ribbon.
11 Close the printer lid until it snaps shut.
12 Print a test label.
Warning: Do not touch the printhead surface area.
