Interroll i Series User Manual

Interroll Drum motor series i, S, S/A, D
i-series product information
Version 4.1 (06/2015) en-US
Translation of original instruction manual
25
P
N
n
P
n
N
f
N
U
N
I
N
cosφ
η
J
R
I
S
/I
N
M
S
/
M
N
M
B
/
M
N
M
P
/
M
N
M
N
R
M
U
SH delta
U
SH star
C
r
kW min
-1
Hz W A kgcm
2
Nm
Ω
V DC V DC µF
0.37 8 828 60 230 2.8 0.62 0.54 22.6 2.8 1.7 1.9 1.6 4.27 18.5 24 - 24
0.37 8 690 50 400 1.5 0.62 0.57 22.6 2.87 1.9 2.35 1.9 5.12 22 - 31 36
0.37 8 828 60 460 1.4 0.62 0.54 22.6 2.8 1.7 1.9 1.6 4.27 18.5 - 48 24
0.37 4 1375 50 230 1.9 0.77 0.66 11.3 3.2 1.6 1.8 1.6 2.7 29.2 21 - -
0.37 4 1375 50 400 1.1 0.77 0.66 11.3 3.2 1.6 1.8 1.6 2.7 29.2 - 37 -
0.455 6 845 50 230 2.04 0.75 0.74 22.6 3.1 1.07 1.07 1.07 5.142 25 19 - -
0.455 6 845 50 400 1.18 0.75 0.74 22.6 3.1 1.07 1.07 1.07 5.142 25 - 33 -
0.55 6 845 50 230 2.77 0.69 0.72 22.6 3.4 1.4 1.65 1.4 6.22 19.5 19 - 38
0.55 6 1060 60 230 2.6 0.8 0.67 22.6 3.4 2.2 2.3 2.1 4.96 19.35 30 - 22
0.55 6 845 50 400 1.6 0.69 0.72 22.6 3.4 1.4 1.65 1.4 6.22 19.5 - 32 38
0.55 6 1060 60 460 1.3 0.8 0.67 22.6 3.4 2.2 2.3 2.1 4.96 19.35 - 60 22
0.62 4 1378 50 230 2.55 0.8 0.76 11.3 3.6
1.26 1.49 1.07 4.297 14.4 15 - -
0.62 4 1378 50 400 1.48 0.8 0.76 11.3 3.6 1.26 1.49 1.07 4.297 14.4 - 26 -
0.75 4 1355 50 230 3.12 0.8 0.75 11.3 3.5 1.53 1.8 1.3 5.29 23.9 30 - 43
0.75 4 1584 60 230 3.1 0.76 0.8 11.3 1.8 1.53 1.4 1.53 4.52 11.95 21 - 27
0.75 4 1355 50 400 1.8 0.8 0.75 11.3 3.5 1.53 1.8 1.3 5.29 23.9 - 52 43
0.75 4 1584 60 460 1.55 0.76 0.8 11.3 1.8 1.53 1.4 1.53 4.52 11.95 - 42 27
0.909 4 1320 50 230 3.92 0.84 0.69 11.3 3.7 1.16 1.24 1.07 6.576 8.3 14 - -
0.909 4 1320 50 400 2.27 0.84 0.69 11.3 3.7 1.16 1.24 1.07 6.576 8.3 - 24 -
0.909 2 2860 50 230 3.3 0.86 0.8 7.3 4.6 2.48 2.64 1.74 3.035 6.2 9 - -
0.909 2 2860 50 400 1.91 0.86 0.8 7.3 4.6 2.48 2.64 1.74 3.035 6.2 - 15 -
1.1 4 1320 50 230 4.85 0.82 0.69 11.3 3.5 1.5 1.7 1.3 7.96 7.2 14 - 67
1.1 4 1320 50 400 2.8 0.82 0.69 11.3 3.5 1.5 1.7 1.3 7.96 7.2 - 25 67
1.1 2 3414 60 230 4.2 0.86 0.77 6.8 3.42 3.15 2.1 3.15 3.08 2.9 8 - -
1.1 2 2845 50 230 4.16 0.86 0.77 7.6 5.2 3.15 3.42 2.1 3.69 2.9 5 - -
1.1 2 3414 60 460 2.1 0.86 0.77 6.8 3.42 3.15 2.1 3.15 3.08 2.9 - 16 -
1.1 2 2845 50 400 2.4 0.86 0.77
7.6 5.2 3.15 3.42 2.1 3.69 2.9 - 9 -
