Interroll Drum motor series i, S, S/A, D
76
Version 4.1 (06/2015) en-US
Translation of original instruction manual
Assembly and installation
Warning notices concerning the installation
CAUTION
Rotating parts and inadvertent startup of the motor
Risk of crushing for fingers
4
Do not reach into areas between drum motor and conveyor belts or roller chains.
4 Install a protection device (such as a guard plate) to prevent fingers from getting trapped in
the chain belts or roller chains.
4
Install an appropriate warning on the conveyor.
NOTICE
Risk of damage leading to failure or shortened service life of the drum motor
4
Observe the following safety information.
4 Do not drop or mishandle the drum motor to avoid internal damages.
4 Prior to the installation, inspect each drum motor for damage after storage.
4 Do not hold, carry, or support the drum motor by the wires extending out of the mounting
shaft to avoid damage to the internal parts and seals.
4
Do not twist the motor cable.
4 Do not overtension the belt.
Installing the drum motor
4 Ensure that the data on the type plate are correct and match the ordered and confirmed
product.
A special design must be used for installing the drum motor in non-horizontal applications.
The exact design must be specified at the time of ordering. In case of doubt, contact Interroll.
The drum motor must be mounted horizontally with a clearance of +/- 5° (drum motor 113S:
+/- 2°; 113S/A: -5°/+15°), unless specified differently in the order confirmation.
Positioning the drum
motor
